iFi - XDSD Gryphon Studio

Akku

USB-C-Ladung, BC1.2-konform bis zu 1900 mA Ladeleistung

DAC

Burr-Brown

Abmessungen

123 × 75 × 19 mm
4.8" × 3.0" × 0.7"

Gewicht (Netto)

215 g (0.5 lbs)

DSD

DSD512 / 256 / 128 / 64 (Octa / Quad / Double / Single-Speed)

PCM

768 / 705.6 / 384 / 352.8 / 192 / 176.4 / 96 / 88.2 / 48 / 44.1 kHz

DXD

768 / 705.6 / 384 / 352.8 kHz (Double / Single-Speed)

MQA (Decoder)

384 / 352.8 kHz

Bluetooth Audio

Bis zu 96 kHz

Kabellos

Bluetooth 5.1 (aptX, aptX HD, aptX Adaptive, aptX LL, LDAC, HWA, AAC, SBC)

Kabelgebunden (Digital)

USB-C, S/PDIF koaxial

Kabelgebunden (Analog)

Balanced 4.4 mm, S/PDIF koaxial

Line-Out

Balanced: 6.7 V max (variabel)
S-Bal (SE): 3.5 V max (variabel)

Kopfhörerausgang

Balanced: 4.4 mm Pentaconn
S-Bal (SE): 3.5 mm SE

Line-Out

Balanced: ≤200 Ω
S-Bal (SE): ≤100 Ω

Kopfhörerausgang

Balanced: S-Bal (SE):

Balanced

>1000 mW @ 32 Ω
>74 mW @ 600 Ω
>6.7 V max @ 600 Ω

S-Bal (SE)

>320 mW @ 32 Ω
>40 mW @ 300 Ω
>3.5 V max @ 600 Ω

SNR

<116 dB(A) @ 0 dBFS

<115 dB(A) @ 0 dBFS

THD+N

<0.007 % @ 0 dBFS

<0.015 % @ 0 dBFS

THD+N (Kopfhörer)

<0.005 % (1 V @ 16 Ω)

–
