Balanced Audio Technology - VK-80 Röhrenvorverstärker
Art.Nr.: bat-vk80
Hersteller: BAT
Breakthrough Design: Third-Generation BAT SuperPak
The VK-80 preamplifier features Balanced Audio Technology’s all-new, third-generation SuperPak in its power supply. The design represents a significant rethinking of what is possible from an energy storage device. For the first time, the BAT SuperPak features hybrid construction that incorporates two capacitors built and potted into each individual shell. An additional silver-in-oil capacitor—arguably the finest-quality capacitor offered at any price in the industry—is used as part of the Gen 3’s construction. The two capacitors are then assembled into a new low-resonance shell. The result: Low-level detail is revealed in a clear and unforced manner, while the overall sound takes on a beguiling sweetness and naturalness from top to bottom.
New Industrial Design for Aesthetics, Flexible Interface for Convenience
Visually, VK-80 features the elegant industrial design first seen in BAT’s flagship REX 3 system. The graceful architecture is complemented by a powerful, easy-to-use customer interface. You can dim the display from the comfort of your chair by using the BAT remote. Fade music at the touch of a button. Switch phase to see if a recording is made in reverse absolute polarity. Even name your sources. For example, name your home-theater playback input “THTR.” Then, fix the volume for your THTR input to control your home-theater system from your pre/pro remote. Love analog? Simply order your VK-80 with BAT’s VK-P3 phono card, which provides switch-selectable moving-magnet and moving-coil gain settings.
The Uncommonly Good Transformer Design Gets Even Better
VK-80 incorporates a second-generation output transformer using the finest Cardas copper winding. With its second-generation transformer-coupled outputs, VK-80 offers an outstandingly dynamic and transparent rendition of the original musical event. Each of the preamplifier’s transformer-coupled outputs comes encapsulated within a mu-metal shield, which is substantially superior to any capacitor in maintaining purity of signal transmission. True to its heritage, VK-80 also uses the 6H30 SuperTube to form a high-current, low-impedance gain stage. For extra convenience, the fully balanced VK-80 incorporates balanced and single-ended inputs (as well as outputs).
Never Fret About Volume Levels Again
The signal in the VK-80 preamplifier is effectively transmitted through only one gain stage. This Unistage™ circuit provides the ultimate simplicity of amplifying the incoming signal only once and uses no global feedback to double-back on the straight-through integrity of said signal. Pass music through too many gain stages, and you’ll no longer recognize the genius and beauty of your favorite recordings. And with VK-80, you can always get the volume just right. A proprietary electronic shunt volume attenuator offers 140 steps of 0.5dB resolution that give precise, repeatable volume settings that sound continuous to the human ear.
Specifications
Hersteller: BAT
Breakthrough Design: Third-Generation BAT SuperPak
The VK-80 preamplifier features Balanced Audio Technology’s all-new, third-generation SuperPak in its power supply. The design represents a significant rethinking of what is possible from an energy storage device. For the first time, the BAT SuperPak features hybrid construction that incorporates two capacitors built and potted into each individual shell. An additional silver-in-oil capacitor—arguably the finest-quality capacitor offered at any price in the industry—is used as part of the Gen 3’s construction. The two capacitors are then assembled into a new low-resonance shell. The result: Low-level detail is revealed in a clear and unforced manner, while the overall sound takes on a beguiling sweetness and naturalness from top to bottom.
New Industrial Design for Aesthetics, Flexible Interface for Convenience
Visually, VK-80 features the elegant industrial design first seen in BAT’s flagship REX 3 system. The graceful architecture is complemented by a powerful, easy-to-use customer interface. You can dim the display from the comfort of your chair by using the BAT remote. Fade music at the touch of a button. Switch phase to see if a recording is made in reverse absolute polarity. Even name your sources. For example, name your home-theater playback input “THTR.” Then, fix the volume for your THTR input to control your home-theater system from your pre/pro remote. Love analog? Simply order your VK-80 with BAT’s VK-P3 phono card, which provides switch-selectable moving-magnet and moving-coil gain settings.
The Uncommonly Good Transformer Design Gets Even Better
VK-80 incorporates a second-generation output transformer using the finest Cardas copper winding. With its second-generation transformer-coupled outputs, VK-80 offers an outstandingly dynamic and transparent rendition of the original musical event. Each of the preamplifier’s transformer-coupled outputs comes encapsulated within a mu-metal shield, which is substantially superior to any capacitor in maintaining purity of signal transmission. True to its heritage, VK-80 also uses the 6H30 SuperTube to form a high-current, low-impedance gain stage. For extra convenience, the fully balanced VK-80 incorporates balanced and single-ended inputs (as well as outputs).
Never Fret About Volume Levels Again
The signal in the VK-80 preamplifier is effectively transmitted through only one gain stage. This Unistage™ circuit provides the ultimate simplicity of amplifying the incoming signal only once and uses no global feedback to double-back on the straight-through integrity of said signal. Pass music through too many gain stages, and you’ll no longer recognize the genius and beauty of your favorite recordings. And with VK-80, you can always get the volume just right. A proprietary electronic shunt volume attenuator offers 140 steps of 0.5dB resolution that give precise, repeatable volume settings that sound continuous to the human ear.
Specifications
- Power Supply: Third generation SuperPak: 4x50uF with internal silver/oil hybrid construction Silver gold oil bypass caps
- Signal Path: Unistage design with only one gain block and no capacitors in signal path
- Output: Second generation output transformers with Cardas OFC wiring
- Global Feedback: None
- Inputs: 2x XLR + 3x RCA
- Outputs - Main: 1x XLR + 1x RCA
- Outputs - Tape: 1x RCA
- Maximum Gain: 18dB
- Volume Control Resolution: 0.5dB
- Volume Control Number of Steps: 140
- Frequency Response: 2Hz to 200kHz
- Input Impedance (minimum): 100kΩ
- Output Impedance: 300Ω
- Noise (unweighted): -96dB
- Distortion at 2V output: 0.005%
- Maximum Output Signal: 30V
- Absolute Polarity: Switchable
- Power Consumption: 150VA
- Tube Complement: 4x 6H30, 2x 6C19
- Dimensions (cm): 49 x 15 x 40
- Weight: 19kg
